The HR22 Dorada II is a cost-effective 2D handheld barcode scanner engineered for high-volume scanning. With a 2200mAh battery delivering 12+ hours of runtime, Bluetooth 5.0 wireless connectivity up to 50 m, and 360° roll tolerance, it performs reliably across retail, warehousing, and logistics environments. Supports all major 1D and 2D symbologies on Windows, Android, macOS, and iOS.
| Parameter | Specification / Standard |
|---|---|
| Model No. | HR22 |
| Type | Handheld |
| Series | Dorada II |
| Battery | 2200 mAh Li-ion |
| Expected Battery Life | ≥12 hours continuous (scan once per 6 s) |
| Charge Time | ≤5.5 hours (with power adapter) |
| Supported OS | Windows XP/7/8/10/11, Linux, Android, macOS, iOS (HID-KBW & BLE) |
| SDK | USB, Android/Windows Bluetooth, Android/iOS |
| Warranty | 3 years |
| Frequency | N/A (Optical Imager) |
| 1D Symbologies | Code 11/39/93/128, GS1-128, Codabar, UPC-A/E, EAN-8/13, ISBN, ITF-6/14, MSI Plessey and more |
| 2D Symbologies | PDF417, Micro PDF417, QR Code, Micro QR, Data Matrix, Aztec |
| Image Sensor | 640×480 CMOS |
| Illumination | White LED |
| Aiming | Red LED (625 nm) |
| DOF — EAN-13 (13 mil) | 45–260 mm |
| DOF — Code 39 (5 mil) | 45–115 mm |
| DOF — PDF417 (6.67 mil) | 50–120 mm |
| DOF — Data Matrix (10 mil) | 35–125 mm |
| DOF — QR Code (15 mil) | 30–170 mm |
| Field of View | 42° (H) × 34° (V) |
| Scan Angle | Roll 360°, Pitch ±60°, Skew ±60° |
| Minimal Print Contrast | 20% |
| Memory Flash | 1 MB |
| Dimensions | 145 × 101 × 68 mm |
| Weight | 167 g |
| Interface | USB |
| Read Range | Up to 50 cm (focus depth) |
| Communication Modes | Synchronous mode, automatic batch mode, manual batch mode |
| Notifications | Beep, LED indicator, vibration |
| Input Voltage | 5VDC ±5% |
| Configuration Tool | EasySet |
| Operating Temperature | -20°C to 60°C (-4°F to 140°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Humidity | 5% to 95% (non-condensing) |
| ESD | ±15 kV air discharge, ±8 kV direct discharge |
| Drop Resistance | 1.5 m |
| IP Rating | IP42 |
| Certifications | Certified |
The HR22 Dorada II is a cost-effective 2D handheld barcode scanner engineered for high-volume scanning. With a 2200mAh battery delivering 12+ hours of runtime, Bluetooth 5.0 wireless connectivity up to 50 m, and 360° roll tolerance, it performs reliably across retail, warehousing, and logistics environments. Supports all major 1D and 2D symbologies on Windows, Android, macOS, and iOS.
| Model No. | HR22 |
| Type | Handheld |
| Series | Dorada II |
| Battery | 2200 mAh Li-ion |
| Expected Battery Life | ≥12 hours continuous (scan once per 6 s) |
| Charge Time | ≤5.5 hours (with power adapter) |
| Supported OS | Windows XP/7/8/10/11, Linux, Android, macOS, iOS (HID-KBW & BLE) |
| SDK | USB, Android/Windows Bluetooth, Android/iOS |
| Warranty | 3 years |
| Frequency | N/A (Optical Imager) |
| 1D Symbologies | Code 11/39/93/128, GS1-128, Codabar, UPC-A/E, EAN-8/13, ISBN, ITF-6/14, MSI Plessey and more |
| 2D Symbologies | PDF417, Micro PDF417, QR Code, Micro QR, Data Matrix, Aztec |
| Image Sensor | 640×480 CMOS |
| Illumination | White LED |
| Aiming | Red LED (625 nm) |
| DOF — EAN-13 (13 mil) | 45–260 mm |
| DOF — Code 39 (5 mil) | 45–115 mm |
| DOF — PDF417 (6.67 mil) | 50–120 mm |
| DOF — Data Matrix (10 mil) | 35–125 mm |
| DOF — QR Code (15 mil) | 30–170 mm |
| Field of View | 42° (H) × 34° (V) |
| Scan Angle | Roll 360°, Pitch ±60°, Skew ±60° |
| Minimal Print Contrast | 20% |
| Memory Flash | 1 MB |
| Dimensions | 145 × 101 × 68 mm |
| Weight | 167 g |
| Interface | USB |
| Read Range | Up to 50 cm (focus depth) |
| Communication Modes | Synchronous mode, automatic batch mode, manual batch mode |
| Notifications | Beep, LED indicator, vibration |
| Input Voltage | 5VDC ±5% |
| Configuration Tool | EasySet |
| Operating Temperature | -20°C to 60°C (-4°F to 140°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Humidity | 5% to 95% (non-condensing) |
| ESD | ±15 kV air discharge, ±8 kV direct discharge |
| Drop Resistance | 1.5 m |
| IP Rating | IP42 |
| Certifications | Certified |
No. POXO barcode scanners are plug-and-play USB HID devices — they behave like a keyboard, so they work with any POS, ERP, or browser form without installs.
2D imager models read from phone screens and tolerate scuffed or low-contrast labels far better than laser scanners.
Handhelds suit counters and spot checks; fixed-mount scanners suit conveyor and kiosk installs where items pass the scanner. We'll recommend the right form factor for your workflow.
